VSXe processors မ်ားသည္ DSP (Digital Sound Processing - ဒစ္ဂ်စ္တယ္နည္းျဖင့္ အသံထိန္းခ်ဳပ္လုပ္ေဆာင္ႏုိင္မႈ) ကို အေျခခံထားၿပီး 96KHz sample rate ကို ထပ္မံတိုးခ်ဲ ့ေစႏုိင္ေသာ စပီကာ ထိန္းခ်ဳပ္မႈ စနစ္ ႏွင့္ flotation point DSP processor ကို အလြန္တိက်ေသာ filter response ေပးစြမ္းႏိုင္သည္။ Crossover filters မ်ားသည္ အျပည့္အဝ ခ်ိန္ညွိႏိုင္ၿပီး ႀကိဳက္ႏွစ္သက္ရာ input ကို ႀကိဳက္ႏွစ္သက္ရာ output သို ့လမ္းေၾကာင္းသတ္မွတ္ႏိုင္သည္။ PC ကြန္ပ်ဴတာအတြက္ VSX Editor Program ျဖင့္ ၿပီးျပည့္စံုေသာ remote Setup ႏွင့္ လုပ္ေဆာင္ခ်က္မ်ားကို စက္ဧ။္ ေရွ ့တြင္ပါဝင္ေသာ USB အေပါက္မွ ခ်ိတ္ဆက္၍ (သို ့) စက္ဧ။္ အေနာက္ဘက္ရွိ Ethernet Network ျဖင့္ ခ်ိတ္ဆက္၍ေဆာင္ရြက္ႏိုင္သည္။ Files မ်ားကိုလဲ သိမ္းႏိုင္ၿပီး Software ျဖင့္ ျပန္ဖြင့္၍လဲ အသံုးျပဳႏိုင္သည္။

Features

Balanced Inputs: VSX 48e 4

4 XLR balanced inputs and 8 XLR balanced outputs VSXe 48

Maximum input and output level +20 dBu, XLR balanced inputs and outputs

Frequency response 20 Hz to 20 kHz +0, -1 dB

5 segment LED meters with limit indication on each output

Every input features Gain, Mute, HP and LP filters, 8 bands of PEQ, polarity and Delay (680 mS)

Security lock

Dynamic range input to output greater than 109 dB (A-weighted) or 107 dB (unweighted)

USB B port for setup and control

24 bit Delta-Sigma A/D and D/A converters

Every output features: 9 bands of PEQ, gain, compressor/limiter, polarity, Delay (680 mS), mute, and crossover/band-pass filters

Ethernet port for setup and control

Channels can be linked for simplified stereo operation

96 kHz Sample rate

Signal generator (sine, white noise, pink noise)

PC Editor Programs allow complete remote setup and operation via USB or Ethernet

Crossover/Band-pass filters feature Butterworth, Bessel or Linkwitz-Riley alignments from 1st order (6 dB/Oct) to 8th order (48 dB/Oct)

Balanced Outputs: VSX 48e 8

EQ filter types include: PEQ, Low-Shelf, Hi-Shelf, Low-Pass, High-Pass, All-Pass1 and All-Pass2

5 segment LED meters on each input

THD+N < 0.01% at 1 kHz

Weight Unpacked: 5.80 lb(2.63 kg)

Weight Packed: 7.72 lb(3.5 kg)

Width Packed: 11.69"(29.6926 cm)

Height Packed: 21.14"(53.6956 cm)

Depth Packed: 4.9"(12.446 cm)
