PR , PVX , PV Series Speaker ၁ လံုးတပ္ ၈ စံု (သို့) QW2F, DPE 115 စပီကာ ၄ စံု (သို့) PV 215, PV 2015, DEP 215, QW 4F စပီကာ ၂ လံုးတပ္ ၂ စံု (သုိ့) QW 118, SP 118 Subwoofer ၄ စံု (သို့) QW 218, SP 218 Subwoofer ၂ စံု (သို့) VR 218 Subwoofer ၁ စံု တုိ့ ကို ဤ amp ၁ လံုးတည္းျဖင့္ အသံုးျပဳႏိုင္ပါသည္။

Features

8 Ohms Stereo Power - 4 x 1350 Watts

4 Ohms Stereo Power - 4 x 2100 Watts

2 Ohms Stereo Power - 4 x 2500 Watts

8 Ohms Bridge Power - 2 x 4200 Watts

4 Ohms Bridge Power - 2 x 5000 Watts

Frequency Response (+0 / -0.3dB, 1 W / 8 Ohms): 20Hz-34KHz

Total Harmonic Distortion 20Hz - 20kHz: <0.1%Singal to noise ratio: > 112dB

Channel Resoluation (crosstalk) 1kHz:>70dB

Input Connector : XLR Female

Output Connector : Speakon seat

Input Inpedance : 20KOhms Balance

Level adjustment : front plate potentiometer, from negative infinity to 0dB

Cooing : stepless speed regulation fan, airflow from front to back

Power amplifier protegtion : short circuit, open circuit, DC voltage, overheating, RF, ultra-low frequency protection

Power Specification : AC 220V (+/-10%) 50-60 Hz

Chassis size (height*widgth*length) : 88mm x 483mm x 396mm

Package size (height*widgth*length) : 180mm x 560mm x 500mm

Net Weight : 12kg

Gross weight : 13.4 kg
